XBOXER XBC

XBC range of high efficiency heat recovery ventilation units designed for ceiling void applications (suitable for external use with weather roof).

Designed to save energy, improve indoor air quality and provide the lowest noise breakout. When used with Nuaire matched attenuators. Available with Inline & bend silencers.

Sales
Tel: 02920858200
Email: Email Us

After Sales Support
Tel: 02920858400
Email: Email Us

Low depth, heat recovery units designed for ceiling void applications (suitable for external use with weather roof).

Features & Benefits:

  • High heat exchange efficiency - Up to 95%
  • Lowest noise – Quietest solution, units are aluzinc, Asymmetric, high mass, double skinned wall construction with specialist acoustic treatment. Matched silencers reduce breakout and can be flipped 180 degrees on site to fit either side.
  • Most compact & flexible - Lowest case height (by duty) with unique supply/discharge are on unit centreline, intake/extract connections are configurable on site to either side of the unit.
  • Optimum performance – Backward curved impellers and IP54 EC motors provide low specific fan powers and step-less speed control without tonal noise generation. Blowers are ErP 2015 compliant.
  • Simplistic control solutions – Energy efficient Ecosmart ‘plug and play’ control along with the addition of Ecosmart2 (powered by Trend). All XBC’s are available with full ecosmart control platform including classic  (ES), Connect (CO), Adapt Trend (AT)

Nuaire XBOXER supply & extract unit with heat recovery.

The unit incorporates a high efficiency counterflow plate heat exchanger (up to 95% efficiency) with segmented 100% bypass facility automatic control and actuator.

Performance optimised backward curved impellers and IP54 EC motors provide low specific fan powers and stepless, speed control without tonal noise generation.

Asymmetric, high mass double skinned wall construction (patented) with integral acoustic barrier mat ensures low breakout noise levels.

Unit is fitted with high capacity pleated G4 panel filters (spare filters are included) for commissioning purposes.

Controller software is pre-configured and the unit / control assembly is functionally tested at works (refer to technical documentation for controller functional specification).

Controls are pre-wired and tested at Nuaire prior to delivery

Low casing height for ceiling / underfloor / slab mounted applications.

Flexibility in unit ductwork connections - Supply / Discharge connections on unit centreline; Intake / Extract connections are configurable on site to either side of unit.

Side mounted unit control. Unit supplied as configuration A (refer to technical documentation). 5 year warranty.

  • Schools
  • Offices
  • Student Accomodation
  • Weather roof
  • Matched attenuators
  • Constant Pressure range
  • Filters G4 as standard (F7 )
